12/1/2024
Euro/USD exchange rate for December 2024 is 1.0562
Euro/USD exchange rate for December 2024 is 1.0562
You can download and run the cloud installer from the location: SchuCad Next 2024.2 manual: https://help.schueco.digital/en/schuecad/2024 SchuCad Next 2024.2 installation manual: After the start, cloud installer will ask for temporary package download location. Just click Select folder button to confirm default: After a while you will see progress window with download time estimation: After this phase installation process will start...
New Schucal 2024 R2 has been published and is ready to install. New Feature SchuCal 2024 R2: https://www.youtube.com/playlist?list=PL1bRABLS_JWz1PTPtqF16hq0X_eHsvSLe This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. File is around 7GB....
Euro/USD exchange rate for November 2024 is 1.0882
SchuCal has an additional component “User-defined design”, which allow the user creating or edit model wireframe in AutoCAD and build model in SchuCal. Below are the requirements for active “User-defined design” function: Obtain the “User-defined design” activation code from your SchuCal support. This function requires active SchuCAD option on the SchuCal license. This function need install SchuCAD next, please follow...
Euro/USD exchange rate for October 2024 is 1.1196
Due to the SchuCal default setting, some profile shows machining process in the SchuCal, but the MCO output program does not has the profile at all. This condition majority happens on the threshold, adapter profile, and attachments profiles. To solve this problem, please follow below steps to change the setting. Go to General > Settings > MCO settings: Select “As...
When user get new computer, may need to transfer the user’s data from the old computer. Locate the user’s data from the old computer. Copy User’s folder and files from old computer. Screen should look like this: Paste User’s folder and files to new computer. Start SchuCal and all the user’s data should be updated in new computer
Euro/USD exchange rate for September 2024 is 1.1087
Engineering Tool Automation Setup V03.02.01 This software package is for TipTronic Simply Smart. TipTronic interface 263175 or Automation manager is required. Download the Engineering Tool Automation from above link. Select the language from the drop-down menu and click next. Follow the installation window’s instruction to install the Engineering Tool Automation.
TipTronic Professional V8.1 software package. This software package is for TipTronic 1.0. TipTronic interface 263175 is required. There are two zipped files under “tip_tronic_professional” folder after unzipped. Please unzipped them. “TipTronic Professional V8.1 (Standard-Version)” is the software package. “Treiber für Busadapter” is the driver file for bus adapter. Open “TipTronic Professional V8.1 (Standard-Version)” folder, find “TipTronic_Prof_V81.exe” file. Double clicks to...
Euro/USD exchange rate for August 2024 is 1.0828
This program modifies Schucal engine to allow implement AWS 114 Insert Window into FWS 50 or FWS SG Steel Look façade. This will work with any AWS 114 Insert Window configuration: Changes: Installer: Procedure after installation: Important: This update does not resolve these important aspects and it is up to fabricator to engineer appropriate solution. Sample sections:
AWS 114 Insert Window for AWS Steel Look Facade
by Adam Koszalkowski · Published July 5, 2024 · Last modified July 8, 2024
This program modifies Schucal engine to allow implement AWS 114 Insert Window into FWS 50 or FWS SG Steel Look façade. This will work with any AWS 114 Insert Window configuration: Installer: Procedure after installation: Important: This update does not resolve these important aspects and it is up to fabricator to engineer appropriate solution. Sample sections:
Euro/USD exchange rate for July 2024 is 1.0705
This program adds US Hurricane configuration for AWS 65, AWS 70.HI and AWS 75.SI series. This version can build US Hurricane configuration for AWS 65, AWS 70.HI and AWS 75.SI configuration together with USA ADA Kickplate and Threshold available here: http://www.schucal-usa.com/category/add-ons/usa-ada-kickplate-and-threshold-for-aws75-aws70/ Download and install here: Changes: Procedure after installation: AWS 65: AWS 70.HI: AWS 75.SI:
This content has restricted access, please type the password below and get access.
Euro/USD exchange rate for June 2024 is 1.0852
New Schucal 2024 R1 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. After start you will see the window with additional information...
Euro/USD exchange rate for May 2024 is 1.0718
Euro/USD exchange rate for April 2024 is 1.0811
Online conference “Recent changes in SchuCal, SchuCad and www.schucal-usa.com website” had a place on March 8, 2024. The topics covered in this conference are listed in following document: schucal-2023-r3-changes-for-us-market/
by Adam Koszalkowski · Published March 14, 2024 · Last modified March 18, 2024
This installer creates ASS 39 PD.NI configuration for Hurricane Resistance System in Schucal.It complies with H9301.01-250-18 Test Report and Schuco USA Information Bulletin #2 June 2019. Download and install here: Changes: This program creates following profiles in database: 9634596 – Extruded handlebar cap 9636963 – Interlock splash guard left 9636964 – Interlock splash guard right 9654625 –...
Performance improvement Some changes have been made to improve program performance with large amounts of data. Please note:Due to this, the first program start may take longer with large amounts of data after installing this service pack. In this case, please be patient and do not cancel the starting process. Projects and items Project glass and project panel:Changes when loading...
by Adam Koszalkowski · Published March 4, 2024 · Last modified March 18, 2024
This installer creates ASS 39 PD.NI configuration for Hurricane Resistance System in Schucal.It complies with H9301.01-250-18 Test Report and Schuco USA Information Bulletin #2 June 2019. Download and install here: Changes: This program creates following profiles in database: 9634596 – Extruded handlebar cap 9636963 – Interlock splash guard left 9636964 – Interlock splash guard right 9654625 –...
by Adam Koszalkowski · Published March 1, 2024 · Last modified March 8, 2024
Euro/USD exchange rate for March 2024 is 1.0826
by Adam Koszalkowski · Published February 7, 2024 · Last modified March 18, 2024
This installer creates ASS 39 PD.NI configuration for Hurricane Resistance System in Schucal.It complies with H9301.01-250-18 Test Report and Schuco USA Information Bulletin #2 June 2019. Download and install here: Changes: This program creates following profiles in database: 9634596 – Extruded handlebar cap 9636963 – Interlock splash guard left 9636964 – Interlock splash guard right 9654625 –...
Euro/USD exchange rate for February 2024 is 1.0000
Schucal is automatically resolving the intercession of profiles connected at their ends. It applies standard connection types depending of profile category. As Schucal is resolving those intersections correctly in majority of cases, is has troubles with the models where more that two profiles are intersecting at one node. As an example lets take the roof construction where rafters are intersecting...
Euro/USD exchange rate for January 2024 is 1.1050
AWS65, AWS70.HI and AWS75.SI Hurricane
by Adam Koszalkowski · Published December 22, 2023 · Last modified December 28, 2023
This program adds US Hurricane configuration for AWS 65, AWS 70.HI and AWS 75.SI series with following types: This version can build US Hurricane configuration for AWS 65, AWS 70.HI and AWS 75.SI configuration together with USA ADA Kickplate and Threshold available here: http://www.schucal-usa.com/category/add-ons/usa-ada-kickplate-and-threshold-for-aws75-aws70/ Download and install here: Changes: Procedure after installation: AWS 65: AWS 70.HI: AWS 75.SI:
New Schucal 2023 R3 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. After start you will see the window with additional information...
Euro/USD exchange rate for December 2023 is 1.0931
Euro/USD exchange rate for November 2023 is 1.0619
This program fixes the problem with Flyscreen for single track ASE 80.HI system in Schucal 2023 R2 Service Pack 4. Installer: Procedure after installation:
After installing SchuCad, double click action on Dimension line runs custom Schucad dimension text editor instead of standard AutoCad one: This action will happen on each of the workspaces, either standard AutoCad or SchuCad profile. Double click action for AutoCad dimension text is overwritten with SchuCad SCC_EDIT command. To fix this, in the command bar type CUI command. In Customizations...
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published October 9, 2023
This program builds USA ADA Kickplate and Threshold easy-access balcony door type configuration for AWS 75.SI and AWS 70.HI systems in Schucal, Inward and Outward opening. It also allows to use 9645954 kickplate profile as the sash bar for inward opening units. Installer: Changes: Procedure after installation: This update modifies each of Opening Option types available for type 152, 153, 432 and 433, inward and outward...
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published October 6, 2023
This program builds USA ADA Kickplate and Threshold easy-access balcony door type configuration for AWS 75.SI and AWS 70.HI systems in Schucal, Inward and Outward opening. It also allows to use 9645954 kickplate profile as the sash bar for inward opening units. Installer: Changes: Procedure after installation: This update modifies each of Opening Option types available for type 152, 153, 432 and 433, inward and outward...
AWS65, AWS70.HI and AWS75.SI Hurricane
by Adam Koszalkowski · Published October 3, 2023 · Last modified October 6, 2023
This program adds US Hurricane configuration for AWS 65, AWS 70.HI and AWS 75.SI series with following types: This version can build US Hurricane configuration for AWS 65, AWS 70.HI and AWS 75.SI configuration together with USA ADA Kickplate and Threshold available here: http://www.schucal-usa.com/category/add-ons/usa-ada-kickplate-and-threshold-for-aws75-aws70/ Download and install here: Changes: Procedure after installation: AWS 65: AWS 70.HI: AWS 75.SI:
Euro/USD exchange rate for October 2023 is 1.0594
Schucal comes with finish calculation module that can automate coating cost estimation. However, Schucal coating price list is not preconfigured and needs to be set up by fabricator after receiving price list from Schuco or other local coater. This is an example of coating price list based on two separate coaters: Schuco Europe and US based company Linetec: Schuco Powder...
Euro/USD exchange rate for September 2023 is 1.0868
You can download and run the cloud installer from the location: After the start, cloud installer will ask for temporary package download location. Just click Select folder button to confirm default: After a while you will see progress window with download time estimation: After this phase installation process will start automatically. Important: After installation Schucad must be initialized. You must...
Euro/USD exchange rate for August 2023 is 1.1023
New Schucal 2023 R2 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. After start you will see the window with additional information...
This program adds US Hurricane configuration for AWS 65, AWS 70.HI and AWS 75.SI series with following types: Download and install here: Changes: Procedure after installation: AWS 65: AWS 70.HI: AWS 75.SI:
This program adds US Hurricane configuration for AWS 65, AWS 70.HI and AWS 75.SI series with following types: Download and install here: Changes: Procedure after installation: AWS 65: AWS 70.HI: AWS 75.SI:
New Schucal 2023 R2 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. After start you will see the window with additional information...
Euro/USD exchange rate for July 2023 is 1.0868
This content has restricted access, please type the password below and get access.
This program adds US Hurricane configuration for AWS 65, AWS 70.HI and AWS 75.SI series with following types: Download and install here: Changes: Procedure after installation: AWS 65: AWS 70.HI: AWS 75.SI:
Euro/USD exchange rate for June 2023 is 1.0732
This installer creates ASS 39 PD.NI configuration for Hurricane Resistance System in Schucal.It complies with H9301.01-250-18 Test Report and Schuco USA Information Bulletin #2 June 2019. Download and install here: Changes: This program creates following profiles in database: 9634596 – Extruded handlebar cap 9636963 – Interlock splash guard left 9636964 – Interlock splash guard right Procedure after...
Software requirements: The first necessary step is to check if each of the units in the project has proper section line defined. Section line in the 3D model defines which 2D details will be included in overall 2D detail set. How to create section line: Open each of the units. Holding left CTRL key on the keyboard select all members...
This program adds US Hurricane configuration for AWS 65, AWS 70.HI and AWS 75.SI series with following types: Download and install here: Changes: Procedure after installation: AWS 65: AWS 70.HI: AWS 75.SI:
UPDATED Euro/USD exchange rate for May 2023 is 1.1032
Euro/USD exchange rate for May 2023 is 1.0000
New Schucal 2023 R1 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. After start you will see the window with additional information...
This program builds US Simulated Double Hung configuration for AWS 90.SI+ system in Schucal according to Schuco Information Bulletin from August 2022. Changes: Installer: [!] This system can be only built with glass thickness in the range of thickness either 28 – 30 mm or 42 – 46 mm. This glass should be defined in the project options. If such glass...
This installer creates ASS 39 PD.NI configuration for Hurricane Resistance System in Schucal.It complies with H9301.01-250-18 Test Report and Schuco USA Information Bulletin #2 June 2019. Download and install here: Changes: This program creates following profiles in database: 9634596 – Extruded handlebar cap 9636963 – Interlock splash guard left 9636964 – Interlock splash guard right Procedure after...
This program adds US Hurricane configuration for AWS 65, AWS 70.HI and AWS 75.SI series with following types: Download and install here: Changes: Procedure after installation: AWS 65: AWS 70.HI: AWS 75.SI:
Euro/USD exchange rate for April 2023 is 1.0905
by Adam Koszalkowski · Published March 31, 2023 · Last modified April 10, 2023
This installer creates ASS 39 PD.NI configuration for Hurricane Resistance System in Schucal.It complies with H9301.01-250-18 Test Report and Schuco USA Information Bulletin #2 June 2019. Download and install here: This program creates following profiles in database: 9634596 – Extruded handlebar cap 9636963 – Interlock splash guard left 9636964 – Interlock splash guard right Procedure after installation:...
AWS65, AWS70.HI and AWS75.SI Hurricane
by Adam Koszalkowski · Published March 7, 2023 · Last modified April 10, 2023
This program adds US Hurricane configuration for AWS 65, AWS 70.HI and AWS 75.SI series with following types: Download and install here: Changes: Procedure after installation: AWS 65: AWS 70.HI: AWS 75.SI:
by Adam Koszalkowski · Published March 1, 2023 · Last modified March 20, 2023
Euro/USD exchange rate for March 2023 is 1.0619
This program activates “classic” PVC Wall Attachment profiles: in FWS 50, FWS 60, FWS 50 SG and FWS 60 SG systems. Installer: Procedure after installation: Samples:
This program creates US SG configuration with 9653367 corner seal adapter for FWS 60 system. Installer: Procedure after installation:
Euro/USD exchange rate for February 2023 is 1.0833
Euro/USD exchange rate for January 2023 is 1.0666
Euro/USD exchange rate for December 2022 is 1.0376
New Schucal 2022 R3 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. After start you will see the window with additional information...
Euro/USD exchange rate for November 2022 is 0.9914
This program builds US Simulated Double Hung configuration for AWS 90.SI+ system in Schucal according to Schuco Information Bulletin from August 2022. Changes: Fixed Glazing Bead Gasket (284836) for 42 – 46 mm glass configuration. Installer: [!] This system can be only built with glass thickness in the range of thickness either 28 – 30 mm or 42 – 46 mm....
This program builds US Simulated Double Hung configuration for AWS 90.SI+ system in Schucal according to Schuco Information Bulletin from August 2022. Installer: [!] This system can be only built with glass thickness in the range of thickness either 28 – 30 mm or 42 – 46 mm. This glass should be defined in the project options. If such glass will...
Euro/USD exchange rate for October 2022 is 0.9748
Euro/USD exchange rate for September 2022 is 1.0000
Schucal has built-in Revit export feature that exports full 3D model to Revit family including unit dimensions and other parameters. You need to meet following software requirements to be able to export the project: – Schucal Enterprise Edition (this feature will not run on Schucal Basic or Advanced) – Autodesk Revit – Schüco Revit Interface – Schucal to Revit export...
Euro/USD exchange rate for August 2022 is 1.0198
New Schucal 2022 R2 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. As of this version each new Schucal will be deployed...
The additions and changes are described in general terms. The availability of the systems, materials and functions depends on your program’s configuration level. You can find the letter detailing the changes that are included in the upcoming service packs for the respective version in the menu ribbon under General > Help > Program information > Service Pack XY > Details....
Euro/USD exchange rate for July 2022 is 1.0387
AWS65, AWS70.HI and AWS75.SI Hurricane
by Adam Koszalkowski · Published June 9, 2022 · Last modified March 7, 2023
This program adds US Hurricane configuration for AWS series for following types: Download and install here: Procedure after installation: AWS 65: AWS 70.HI: AWS 75.SI:
Euro/USD exchange rate for June 2022 is 1.0713
by Adam Koszalkowski · Published May 3, 2022 · Last modified September 25, 2023
This program creates US SG configuration with 307660 seal adapter for FWS 60 system. The configuration can be built with either cover cap or wet/gasket seal, alternate (horizontal vs vertical) or mixed pattern (independent decision for each mullion/transom). This add-on can be used to build FWS 60 Hurricane system according to Intertek Report K2521.01-250.44 R0 Installer: Procedure after installation: You...
Euro/USD exchange rate for May 2022 is 1.0540
by Adam Koszalkowski · Published April 7, 2022 · Last modified April 12, 2022
Installer creates ASS 39 PD.NI configuration for Hurricane Resistance System.It creates configuration according to H9301.01-250-18 Test Report. Download and install here: This program creates following profiles in database: Extruded handlebar cap 9634596Interlock splash guardleft 9636963Interlock splash guardright 9636964 Procedure after installation: 1. Start/restart Schucal 2. Create new unit in SchuCal as template go to: Own Templates >...
During download process of Schucal installer I got the error “Hash mismatch for downloaded block!“: This problem is caused by unstable or slow network connection. Please close this window and start installer again. The installer will continue adding content to previously downloaded data from the cloud, so you do not waste already downloaded content.This error can occur multiple times, so...
Schucal can be activated with temporary trial license for 90 days. To process it please start Schucal without any license dongle inserted. Schucal will display Schucal License activation window: Select and copy Request code highlighted red on the screenshot above. Send the code to adam@schuco-usa.com After receiving the activation code paste it in the License activation number / Activation code...
by Adam Koszalkowski · Published April 1, 2022 · Last modified April 5, 2022
Euro/USD exchange rate for April 2022 is 1.1101
New Schucal 2022 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. Warning: Schucal users who have installed custom systems/profiles prepared for US...
I. General program changes (for all design types) Output lists Unit overview list:Flexible lists – Beta version for testing (Only program versions 64-bit.) If you have set the language for the program interface as German, you will find the Use flexible list (beta) option in the settings for the Unit overview list. By checking this box, you are able to...
Euro/USD exchange rate for March 2022 is 1.1199
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published February 15, 2022
This program builds USA ADA Kickplate and Threshold easy-access balcony door type configuration for AWS 75.SI and AWS 70.HI systems in Schucal, Inward and Outward opening. It also allows to use 9645954 kickplate profile as the sash bar for inward opening units. Installer: Changes: Added kickplates for AWS 70.HI system: 9635019 (Outward) and 9645953 (Inward) Procedure after installation: Start/Restart SchuCal Create/Open AWS 75.SI or AWS 70.HI family unit...
Euro/USD exchange rate for February 2022 is 1.1156
Euro/USD exchange rate for January 2022 is 1.1323
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published December 16, 2021
This program builds USA ADA Kickplate and Threshold for AWS 75.SI easy-access balcony door type configuration in Schucal, Inward and Outward opening. It also allows to use 9645954 kickplate profile as the sash bar for inward opening units. Installer: Changes: Fixed kickplate/transom 9634794 internal half profile data. Now it is correct 345300. Fixed glazing rebate insulation algorithm for 9634794 kickplate. Now it properly selected depending on...
Sample AutoCad project file contains white text label object placed over the grey solid hatch area, as on the example below : After generating Batch Plot to PDF file the text object disappears from the print area: Solution: The problem is caused by improper setting of blending/merging of the overlapping lines.You can fix this by changing Merge Control setting in...
Euro/USD exchange rate for December 2021 is 1.1363
New Schucal 2021 R3 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. Warning: Schucal users who have installed custom systems/profiles prepared for...
General program changes Calculation Surcharges on material and coatings(Since 2021 R2 SP03, SP04, SP05, SP06) The current fluctuations in raw material prices, which are sometimes huge, require variable options which must be taken into account in the program. Entry options have been added to the system and coating conditions for various material/discount groups and for coatings. Surcharge for material: For...
Euro/USD exchange rate for November 2021 is 1.1645
Euro/USD exchange rate for November 2021 is 1.1617
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published October 22, 2021
This program builds USA ADA Kickplate and Threshold for AWS 75.SI easy-access balcony door type configuration in Schucal, Inward and Outward opening. It also allows to use 9645954 kickplate profile as the sash bar for inward opening units. Installer: Changes: ADA Kickplate works now with double vent windows doors, Schucal opening types 432 and 433, inward and outward. Procedure after installation: Start/Restart SchuCal Create/Open AWS 75.SI Family unit...
Euro/USD exchange rate for October 2021 is 1.1579
SchuCad is ready to install. You can download and run the cloud installer from the location: After the start, cloud installer will ask for temporary package download location. Just click Select folder button to confirm default: After a while you will see progress window with download time estimation: After this phase installation process will start automatically. Important: After installation Schucad...
In recent days Schucal can return the following error during the start: The operating system is not presently configured to run this application: This message can keep looping and cannot be closed. In this case you need to kill it in Task Manager: CTRL-ALT-DELETE -> Task Manager > select Schucal process and click End Task. Schucal software itself cannot be...
Euro/USD exchange rate for September 2021 is 1.1834
In specific circumstances it can happen that while generating the report to Excel Schucal can return the error with one of few possible messages, for example as this: This problem requires reinitialization of Schucal-Excel connector. Please close Schucal and start Excel in Administration mode, Menu start > Right mouse button on Excel icon > More > Run as administrator: Go...
If you need to build custom glass bite for FWS curtain wall family, what can be necessary if you have special approval, you can do it with standard Schucal tools. In the example below we will make custom gap size between glass panels as 7/8″ (22mm) for horizontal and 1″ (25mm) for vertical divisions, what is defined by Test Report...
Euro/USD exchange rate for August 2021 is 1.1891
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published July 26, 2021
This program builds USA ADA Kickplate and Threshold for AWS 75.SI easy-access balcony door type configuration in Schucal, Inward and Outward opening. It also allows to use 9645954 kickplate profile as the sash bar for inward opening units. Installer: Changes: Fixed bars and isobars number descriptions for 9634794 kickplate/sash bar Procedure after installation: Restart SchuCal Create/Open AWS 75.SI Family unit Set Opening Type to type 152 or 153 Go to Item properties > Settings...
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published July 23, 2021
This program builds USA ADA Kickplate and Threshold for AWS 75.SI easy-access balcony door type configuration in Schucal. Now it also allows to use 9645954 kickplate profile as the sash bar for inward opening units. Installer: Changes: T-cleats for profile 9645954 is generated now properly as 9634796 Improved formula for calculating quantity of 203108 retaining clip Added 298441 joint seal tape for 9634795 Procedure after installation:...
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published July 22, 2021
This program builds USA ADA Kickplate and Threshold for AWS 75.SI easy-access balcony door type configuration in Schucal. Now it also allows to use 9645954 kickplate profile as the sash bar for inward opening units. Installer: Changes: Kickplate profile for all inward opening units received proper V8 number 9645954 The same 9645954 kickplate profile can be used as balcony door sash bar (see the explanation example...
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published July 9, 2021
This program builds USA ADA Kickplate and Threshold for AWS 75.SI easy-access balcony door type configuration in Schucal. Installer: Changes: Added ADA kickplate for inward opening balcony door Procedure after installation: Restart SchuCal Create/Open AWS 75.SI Family unit Set Opening Type to type 152 or 153 Go to Item properties > Settings > Technical settings > USA Settings and check on:USA ADA Threshold Gasket and/or USA ADA Kickplate This update modifies each of Opening Option types available...
New Schucal 2021 R2 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. Warning: Schucal users who have installed custom systems/profiles prepared for...
General program changes (for all design types) Settings Company contact:Account number for delivery addresses As of this version, you can provide account numbers for your delivery addresses in the Company contact dialog box. The fields for the delivery addresses are no longer mandatory either. Output lists Order:Changes for the “project number” in the shipping specifications In previous versions, a Project...
Euro/USD exchange rate for July 2021 is 1.1884
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published June 11, 2021 · Last modified June 12, 2021
Changes: Added two 178476 gasket pieces for 9638948 threshold gasket.
Euro/USD exchange rate for June 2021 is 1.2201
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published May 26, 2021 · Last modified June 12, 2021
Changes: Activation checkboxes USA ADA Threshold Gasket and USA ADA Kickplate moved under new category USA Settings Fixed minor other problems
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published May 24, 2021 · Last modified June 11, 2021
Changes: Updated for Schucal 2021
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published May 19, 2021 · Last modified June 11, 2021
Updated for Schucal 2021 Updated quantity formula for 203108 Retaining Clip to match Intertek Report J9865.02 Added 298441 Sealing Tape to match Intertek Report J9865.02
USA ADA Kickplate and Threshold for AWS75.SI and AWS 70.HI
by Adam Koszalkowski · Published May 18, 2021 · Last modified June 12, 2021
This program builds USA ADA Kickplate and Threshold for AWS 75.SI for easy-access balcony door type configuration in Schucal.
New Schucal 2021 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. Warning: Schucal users who have installed custom systems/profiles prepared for US...
Projects and items Project window:Information about the U value, airborne sound reduction and MCO in the item properties list As of this version, the project window in the Item properties list will display additional information on the currently selected item. U value and airborne sound reduction value: If a value has been calculated for the item, it is shown. If...
Euro/USD exchange rate for May 2021 is 1.2082
by Adam Koszalkowski · Published April 1, 2021 · Last modified July 1, 2021
Euro/USD exchange rate for April 2021 is 1.1725
Administration > User Settings Information about spacer blocks The message is displayed in the item window and the message list: Spacer blocks must be positioned in accordance with the glazing guidelines and packed with compression-resistant packing. They are not calculated automatically and must be entered as additional material. In the User settings dialog box, you can find a checkbox under...
New Schucal 2020 R2 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. Warning: Schucal users who have installed custom systems/profiles prepared for...
Finish (coating) data is stored in project configuration and is transferred with the project either you open it from the server database, local or import from external user by zip file. When you import or open the project your Schucal is using project data to render calculation, not your configuration database. For that reason, the situation when two separate projects...
Schucal FWS family has two options for creating profile joint for mullion or transom. The first type is Profile Division. This is the simple method that creates divisions for all profile members (mullion, pressure plate, cover cap, insulator). This method only divides the members, does not add any structural connectors to the division. Right click on the profile you want...
Program information Overview of the functions used and the options available As of this version, information about the functions used and options available for the workstation are listed under the heading Product license and features on the Help tab (menu ribbon: General > Help > Program information). If your workstation works on a network license, license options that are already...
Schucal network license manager can have problems with distributing license over subnets that are behind the NAT in the network. To workaround it please start web browser on machine with such problem and browse to: http://localhost:1947 Go to Configuration > Access to Remote License Managers and: Check Aggressive Search for Remote Licenses to ON Type IP address of the License...
New Schucal 2020 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. Warning: Schucal users who have installed custom systems/profiles prepared for US...
Schucal is lacking the ability to generate bar codes on predefined reports (outputs). The only exception is the output Output > Other lists > Print label which generates labels for cutting optimization and provides the bar code. However, this is hard to customize to the user’s needs. More information about this report and general information about bar code standards you...
This feature is added to AutoCad by SchuCad and SchuCad Next – new version of SchuCad that is installed in one package together. The idea of this behavior was to maintain CAD drawing standards and position all objects on predefined layer. There are two possible layers that AutoCad (SchuCad) can place newly created dimension objects: OS-Dimension (color 4) or DIM...
On Tuesday Nov 13, 2019 Microsoft released an update for the Access Database Engine of Windows. Schucal is using Microsoft Access Database Engine as primary database driver and after this update it cannot be started any more returning SQL error listed above. This problem occurs only on the systems with specific Microsoft Office installed. This problem is caused by Microsoft...
General Contacts:Supplements for aluminum surface finishes – fixed lengths In the Contacts dialog box, new input options for supplements for small bar lengths have been included for the system coater Schüco and for the coater templates for third-party coaters. In the conditions, new input fields are available for the following Fixed lengths under the Aluminum surface finish supplements group: <...
New Schucal 2019 R3 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. Warning: Schucal users who have installed custom systems/profiles prepared for...
Schuco FWS SG (Structural Glazing) curtain wall glass panels can be built with one of the two toggle fixing versions: SG Spacer or Plastic Pocket. Plastic pockets are the parts inserted between glass panes with offset described in K1011008 drawing. Schucal can prepare plan of Plastic Pocket locations after checking the setting on: Technical Settings > Glazing > Plastic pocket...
New Schucal 2019 R2 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. Warning: Schucal users who have installed custom systems/profiles prepared for...
New Schucal 2019 has been published and is ready to install. This is a critical update. Please install it as soon as possible, your actual Schucal version does not sync service packs and actual price lists anymore. That makes Schucal not compatible with actual system definitions and material prices. Warning: Schucal users who have installed custom systems/profiles prepared for US...
Create the unit with regular mullion: On the 3D model right click on this mullion and choose Generate coupling: Schucal will ask you to pick two profiles, left and right. Select left expansion profile: After that select second, right expansion profile: Choose coupling type: That’s it. Coupling mullion is created:
Schucal server database is available for dedicated users working in local network or external location over VPN. Server database advantages: Projects exchange All Schucal projects are instantly accessible for all Schucal server users. It is not necessary to export/import projects to exchange the work over the office. Roles separation Each user belongs to one or more Schucal group. – Drafting:...
Right click the interlock and go to SLF interlock … section > Modify section: From section list select one with reinforcement: As we can see reinforcement profiles are inserted: As K15170 drawing for ASS 70.HI shows 202792 reinforcement profile must be 120mm shorter than main vent frame profile: This can be checked on Cutting optimization. On this example we can...
Ventilated Vent AWS VV is opaque opening unit. Units are available in widths 170mm, 250mm and 300mm and are designed for quick internal space ventilation. Vent panels are infills for standard AWS frames and are compatible with following systems: To create such unit in Schucal simple create window from the family listed above: You can create single or multi area...
Your CNC software needs profile DXF definition to be able to define profile clamping position and boundary. Majority of stock Schuco profiles are usually built in the CNC software but for any custom profile you need to manually export DXF definition form Schucal and import / save it on your machine. Go to General > Master data > User-defined clamping...
Schucal is natively metric software but can be set to work with Imperial units. To do that go to General > Settings > User settings > Administrator (or any other actual user) > Country settings > System of units You can change units to: SI (Metric) – Native metric Imperial – Fully imperial SI and Imperial – Hybrid (metric /...
Schuco thermally broken profiles can be ordered in one of three rolling codes: SV Schuco pre-rolled (Schüco Verbund) Composite profiles are delivered rolled and coated already. Schuco coats half bars and rolls it all together. WV Pre-rolled (Werksverbund) Composite profiles are delivered rolled already, mill finish. Customer coats the composite profile, avoiding exceeding 180C during coating. KV For rolling by...
There is not such property on the Settings (Technical/Processing) data panel, but it is possible to manipulate with any MCO/CNC processing using Filter tools. First, select the profile for which you want to modify processing and click Processing button. (Hint: Processing functionality needs special Schucal license programmed on Schucal USB dongle and additional activation code. Please contact Schuco USA to...
Here are few steps that you must do in Schucal to build AWS 75.SI+ Outward Opening Easy Access Threshold. As template, pick Windows & Doors > Doors > Outward Opening > Single Leaf door Click Outer Frame property field and pick profile no 480850 or similar. You can find it in subcategory Can also be used as… Do not worry...
Following systems have been removed from the Schüco offer and will no longer be available in SchuCal 2016 R2: Schüco FW 50+ Schüco FW 50+.1 Schüco FW 50+.HI Schüco FW 50+.SI Schüco FW 50+.SI Green Schüco FW 50+S Schüco FW 50+S.1 Schüco FW 50+S.HI Schüco FW 50+ S.SI Schüco FW 60+ Schüco FW 60+.1 Schüco FW 60+.HI Schüco FW 60+.SI...
The number of profile on the output consists of two parts: Two letters symbol that represents profile type (Abbreviations list below) and ID number of the profile referring to the elevation position. On the example below Ri6 is Transom on the position no. 6 (Ri refers to Transom according to the shortcut list below. From German language Riegel) Abbreviations for...
Schuco Converter is a tool upload Schucal cutting lists to FOM saw. At the beginning of work with converter you need to configure few basic parameters. Language: User interface language IP Address: Saw IP address. Default is 192.168.0.200 Ftp default volume: Saw has two internal drives where stores files: D and F. In most cases use D:. Dxf archive: Folder...
Additional material can be put in two ways: related to existing profile from calculation when it takes its length or by manual input. Method one. First, the easiest way: Additional material related to existing profile. Click the profile to which you want to add additional material: In Enter Art. No. under Profile properties window type or search additional material you...
Problem is caused by geometrical modification of the frame grid in the past. As we can see vertical profile No 3 is logically a Mullion, instead of being the Outer Frame. Mullions/Transoms always have construction axis in the middle, Outer Frames on the edge. If we would review the project history, we can find that on 5/20/2016 frame had correct...
There are few steps to achieve it that comes to one goal: remove internal glazing gasket and replace it with 307660 adapter for mullions and appropriate transom gasket. First, go to Settings > Design and change Mullion cover to Silicon joint: Now open Gasket category and set Glazing gasket, inside to Without gasket: Since adapter profile does not exist in...
When you obtained discount quotes from Schuco USA you should set it up in Schucal program to get proper price quotations. To do it, open SchuCal and go to Master Data > Contacts: In Contacts, on the left panel click Schüco Article Supplier: In right panel, slide the window content down and find Conditions for aluminum systems. In filed Description...
To create 90 deg corner façade it is necessary to start project form the scratch and choose Modular façade, polygon: As a scratch system prepares four 1500 mm module, 125° angle wireframe model: This polygon template does not provide direct dimension editing, so the only way to change the dimensions is editing parameters in Item Properties window. To design 90°...
According to attached pdf 448160, here is explanation of surfaces: A – Full profile B – Mech / Polished – visible part of the profile , painted surface (Continous line) (USA only) C – Uml / Total – Total external circumference. Anodised surface D – Do not paint (dash line) E – Beshichted / Coated – pained surface (dash dot...
Crank operated fitting requires window AWS 70.HI or AWS 75.SI system and KDK fitting type: Create window AWS 70.HI or AWS 75.SI with opening type 300: TT DIN left window or 301: TT DIN right window with the range of minimal and maximal size as on the tables: After creating such window select the vent and select Type of operation...
Schucal has built in module for calculating labor time and cost. It can precisely calculate each task of production process: design, profile process, cutting, installing, glazing, sealing, dispatching. Important: This module is hidden by default, must be unlocked by code provided by Schuco. To do this it is necessary to configure two main parameters for each task: hourly rate and...
User has access to SchuCal List & Label Designer where it is possible to add, delete or modify the labels as well as rearrange its positions. To modify the template we must create copy of Barcode Label template first. Go to : C:\ProgramData\Schueco\SchueCal\System\Data\Templates and find file Labels.lbl. Create the copy of it: You can leave the name as default (Labels...
By default Schucal gets the license in “High-to-Low” chronological order. It means the first users that are requesting license get Enterprise license, till available. Next users are receiving Advanced license till they are available, rest of users get Basic license. If number of active users exceed the number of licenses, new license request will be rejected and no license will...
Polygonal façade template does not offer direct dimension modification. The only dimensions user should enter in parametric properties window are: Height Number of surfaces Angle between surfaces Length of surfaces All other subdivisions and its dimensions are defined by direct modification of the surface by Right Mouse Button – Split / Merge / Delete / Add Area on the Left|Right|Top|Bottom....
Solution: The problem happens when on skylight unit you want to have drainage channel gasket installed. You enable it under Item properties window > Settings > Schuco FW 50[60] **.** > Technical settings > Gasket After checking it on, in normal condition you have glass gasket 224981 (or 224982) with drainage channel to collect condensate from the glass installed on...
By default SchuCal works in local configuration, saving all user profiles, projects, settings and templates on local drive. If you want to share this content over the network you should configure SchuCal to work in network mode. To do that first it is necessary to prepare network shared folder on the server and grant network user rights allowing to open,...
By default, unless no other drive and directory have been selected during installation process, SchuCal stores program data in two directories: ProgramData location stores all important configuration data and user profile content. Among others there are three directories keeping all your critical personal data. These locations can be edited by changing Desktop Settings under General > Settings.
Each polygonal façade is constructed on mesh reference plan. In first phase of construction you work on geometrical division, defining module lengths and angles between them: Reference plan in one of two surfaces of the glass / panel chosen for the façade: internal or external (inside or outside). When you select “inside”, the reference plan marked with red line is...
Let’s take AWS/ADS 75.SI+ Double vent TT/SH door as an example. Fitting type Basic. Window Fittings Order Manual specifies 243031 Corner Drive item for this door: But when I generate Order List I see that Schucal calculates Corner block 243028 instead: The problems comes from different packing units (PU) that same item can be ordered. When we go to Order...
By default, whenever other drive and directory has not been selected while installation process SchuCal stores program data in two directories: ProgramData location is storing all important configuration data and user profile content. Among others there are three directories keeping all your critical personal data. You can change your user profiles and project location editing Desktop Settings under General >...
Solution: SchuCal door template set provides single and double leaf door types. Double leaf door is generated as symmetrical, however there is a simply method to change it to any asymmetrical type. To do that, select any double door form predefined types: After doors are created select it and under “Dim.” properties find parameter called “b1-Dim”. Set this value to...
MCO functionality is enabled on client’s request. After email request you will receive numeric code that has to be entered in Schucal configuration. SchuCal Toolbox, small maintenance application installed together with SchuCal is right tool for that. You can find it under menu Start: On main Toolbox window click the button “Additional Components”: Select appropriate language for you and click...
This problem comes from misunderstanding the printout order after generating the Order List. This output generates three lists: Message List, Order list and Coating Plan list. Coting plan list is generated only if you set up Surface finish in project. To switch between lists click its header bar with title. Use Order list to print material quantity list and its...
SchuCal base currency is the Euro and in this currency price lists are deployed online to SchuCal. Each month Schuco USA publishes a new currency conversion rate from Euro to USD. This conversion rate is sent to you via email, and it is necessary to set it in SchuCal to have calculation cost correct. Depending of SchuCal database configuration you...
Couse of problem: In ASS FD system user have to manually choose lock, door handle spindle, gearbox, profile cylinder and rosette as additional material. Articles must be chosen form same article group (Sliding door) and assigned to corresponding leaves. Problem occurred because user selected lock accessories from ADS product group instead of ASS. Not all ADS accessories are compatible with...
Decision about fittings type for the unit depends on burglary resistance class and water tightness class intended for the window. Both classes are defined by architect or client. To set up this decision in Schucal, click window vent in the center: On left window panel you will see following properties: Fittings Click Fittings type filed and choose between available fittings....
The goal is to create processing formula that generates drainage slots in equal distance on divided frame, when total length of its profile cannot be read by variable in processing formula editor after its dividing. First, lets divide profile with splice with 275 mm left offset from its length midlepoint. Select profile by right mouse button and choose Add profile...
Go to General > Settings > Saw settings In saw settings windows set up: User name By entering a number in this field you can modify the generation of the first two digits of the file name. If you leave the entry field empty, the file name is made up of the year and month, followed by a four-digit number....
Go to General > Settings > User settings: To create, change or delete users click Administration button: You will be asked for administration password, which was created on installation time. If you did not specify this password, leave field empty and confirm OK: Click button New user and define new user’s name. Warning: Change immediately ‘New user’ name to real...
Not all Schuco profiles are existing in PBX Schueco CAM software. If you cannot find profile number, you must create one. This process is performed by exporting profile file from Schucal and importing it to SchueCAM. Let’s go through the example of creating two profiles: no. 435940 and 435950. To do that, open Schucal first and go to General >...
Go to General > Settings > Saw settings: In saw settings windows set up: Current user By entering a number in this field you can modify the generation of the first two digits of the file name. If you leave the entry field empty, the file name is made up of the year and month, followed by a four-digit number....
Create or open the project and go to Output > Order list In Output option windows click Optimization settings Check Manipulate optimization Confirm OK, then Click OK on Output options window. Since now, always when you will prepare Order list, you will see form to edit optimization values, including bar lengths. Change value in Fixed length column to desired: Confirm OK...
